F51314 Residential Energy Storage Battery Series
Product Features
- Widely Compatibility: support major leading inverter brands and conventional
VRLA powered system. - Superior Safety: build-in BMS——eliminates the risk of explosion or combustion
due to high impact, overcharging or short circuit situation with safe lithium iron
phosphate chemist. - Flexible Configuration: floor stand design easy to be installed. Optional HMI,
max. 16 sets in parallel supported. - High Performance: support 1C or 100A charge/discharge, widely working
temperature. Cells comply with CE, UL and IEC standards.
Specifications:
Technical Parameters
- Nominal Voltage (V) 51.2
- Nominal Capacity (Ah) 314
- Operating Voltage Range (V)
- Standard Charge/Discharge Current (A)
- Max. Charge/Discharge Current (A) 180 CH / 180 DCH
- Peak Output Current (A) 200@10s
- Lithium Chemistry LiFePOâ‚„
- Cycle Life 6000 @ 0.5C 80% DOD
- Design Life 20 years
- Scalability Max 16P (less than 8P need no external setup)
- Installation Floor stand
Mechanical Specifications
- Dimension (mm) W591 * D157.5 * H1025
- Weight (kg) Approx. 130
- Communication RS485, CAN
- Ingress Rating IP 54
- Safety Standards UN38.3, CE
Operating Performance
- 6000 Cycles & 80% DOD
5 Years Warranty
