Reduce your electricity costs by managing power from various energy sources, including solar panels, batteries, Eskom, generator or wind turbine – all with a Sunsynk Hybrid Inverter.

Original price was: R94,500.00.Current price is: R90,500.00.

10 in stock

10 in stock

Description

8kva Sunsynk & 2 x 5.1kw Dyness with 12 x 550w Solar panels incl. Mounting kit



This multifunctional Sunsynk 8kw hybrid solar inverter combines the functions of an inverter, solar charger, and battery charger to offer uninterruptible power support with a portable size. Its comprehensive LCD display offers user-configurable and easily accessible button operations such as battery charging, AC/solar charging, and acceptable input voltage based on different. applications.

The Sunsynk 8kw hybrid solar inverter comes in as one of the best hybrid inverters in the price category. Sunsynk 8kw hybrid solar inverters offer one of the best value-for-money inverters in the market. With functionality to rival the best out there, at a price point that won’t make you fall off your seat.

Reduce your electricity costs by managing power from various energy sources, including solar panels, batteries, the national electricity grid, a generator, or even a wind turbine – all with a Sunsynk 8kw hybrid solar inverter. It’s ideal for home and business and scalable so that you can expand it as required.

This Inverter is a highly efficient power management tool that allows the user to hit those ‘parity’ targets by managing power coming from multiple sources such as solar, mains grid, and generator and then effectively storing and releasing electric power as the utilities require. The Sunsynk 8kW hybrid Inverter has many uses and is recommended for the following applications:

  • Marine (vessel power management)
  • Power shedding (home/office/factory)
  • UPS (fuel saving systems)
  • Remote locations with solar and wind generators
  • Building sites
  • Military locations
  • Telecommunication sites



Higher yields

  • Improve your self-consumption ratio by up to 80%, reducing your electricity bill.
  • DC/AC ratio up to 1.3, completely suitable for double-side PV modular.
  • Two MPPT designs, Max. efficiency of 97.6%.

User-friendly

  • LCD Touch screen and buttons, easy operation.
  • Compatible with lithium-ion battery and lead acid battery.
  • Web browser and mobile App monitoring are supported.

Reliable

  • PV lighting protection, Anti-islanding protection, Leakage current protection, etc.
  • Support store energy from DG when needed, and ensure the system is working within 7*24H.
  • IP65 protection degree, adapt to indoor and outdoor use.
  • Automatically switch from on-grid to off-grid mode within 5ms.
  • Zero exporting function, fast reaction within 200ms in zero export mode.

Smart

  • Programmable charging and discharging schedule.
  • Both wind turbines and solar panels can be connected as DC input power.
  • Max. 16 units can be paralleled for higher system power.
  • Retrofitting of existing solar system to energy storage system.

Battery Input Data

  • Battery Type: Lead-acid or Li-lon
  • Battery Voltage Range (V): 40-60V
  • Max. Charging Current (A): 190A
  • Max. Discharging Current (A): 190A
  • Charging curve: 3 Stages/Equalization
  • External Temperature Sensor: Optional
  • Charging Strategy for Lithium Battery: Self-adaption to BMS

PV String Input Data

  • Max. DC Input Power (W): 10400W.
  • PV input Voltage (V): 370V (100V-500V).
  • MPPT Range (V): 125-425V.
  • Start-up Voltage (V): 150V.
  • PV Input Current (A): 22A + 22A.
  • No. of MPPT Trackers: 2
  • No. of Strings Per MPPT Tracker: 2+2.

AC Output Data

  • Rated AC Output and UPS Power (W): 8000W
  • Max AC Output Power (W): 8800W
  • Peak Power(off-grid): 2 times of rated power, 10 S.
  • AC Output Rated Current(A): 33.4A/35A
  • Max.AC Output Current(A): 36.7A/38.5A.
  • Max Continuous AC Pass-through(A): 50A.
  • Output Frequency and Voltage: 50/60Hz; 120/240Vac(split phase), 208Vac(2/3 phase), 230Vac(single phase)
  • Grid Type: THD<3%(Linear load<1.5%).
  • Current Harmonic Distortion: THD<3% (Linear load<1.5%).

Efficiency

  • Max. Efficiency: 97.60%
  • Euro Efficiency: 97.00%
  • MPPT Efficiency: 99.90%

Protection

  • PV Arc Fault Detection: Integrated (Except European Type)
  • PV Input Lightning Protection: Integrated
  • Anti -islanding Protection: Integrated
  • PV String Input Reverse Polarity Protection: Integrated
  • Insulation Resistor Detection: Integrated
  • Residual Current Monitoring Unit: Integrated
  • Output over Current Protection: Integrated
  • Output Shorted Protection: Integrated
  • Output over Voltage Protection: Integrated

Certifications and Standards

  • Grid Regulation: UL1741, IEEE1547, RULE21, VDE0126, AS4777, NRS2017, G98, G99, IEC61683, IEC62116, IE61727
  • Safety Regulation: IEC62109-1, IEC62109-2
  • EMC: EN61000-6-1, EN61000-6-3, FCC 15 class B

General Data

  • Operating Temperature Range ( C ): -25—60 C , >45 C Derating
  • Cooling: Fan
  • Noise (dB): <30
  • Communication with BMS: RS485; CAN
  • Weight (kg): 32
  • Size (mm): 680 X 4200 X 233mm
  • Protection Degree: IP65
  • Installation Style: Wall-mounted
  • Warranty: 5 years



Dyness 5.12kWh Block Lithium-ion Battery

BX51100 lithium iron phosphate battery system is a standard battery system unit, customers can choose a certain number of BX51100 according to their needs, by connecting parallel to form a larger capacity battery pack, to meet the user’s long-term power supply needs. The product is especially suitable for energy storage applications with high operating temperatures, limited installation space, long power backup time, and long service life.

Dyness 5.12kWh BX51100 Lithium-ion Battery, model BX51100 LFP Module pack comes with a BMS battery management system that protects against overcharging, over-discharging and short circuits. The Dyness BX51100 5.12kwh lithium battery delivers continuous output power for improved performance and dependability.

The Dyness 5.12kwh BX51100 lithium battery, our newest energy storage solution for renewable energy systems. BX51100 Dyness 5.12kwh is the perfect power backup.

Dynes BX51100 is a 5.12kWh lithium battery suitable for use with renewable energy sources, such as solar panels. The BX51100 Dynes 5.12kwh lithium battery BX51100 LFP Module is a 5.12kWh lithium battery that stores electricity generated by renewable energy sources, and stores for later use when required. It is designed to offer the user complete independence from the National grid.

BX51100 energy storage product’s positive electrode materials are lithium iron phosphate, battery cells are managed effectively by BMS with better performance, the system’s features as below:

  • Comply with European ROHS, Certified SGS, employ non-toxic, non-pollution environment-friendly battery.
  • Anode materials are lithium iron phosphate (LiFePO4), safer with a longer life span.
  • Carries battery management system with better performance possesses protection functions like over-discharge, over-charge, over-current, abnormal temperature.
  • Self-management on charging and discharging, Single-core balancing function.
  • Intelligent design configures an integrated inspection module.
  • Flexible configurations allow parallel of multi-battery for longer standby time.
  • Self-ventilation with lower system noise.
  • Less battery self-discharge, then recharging period can be up to 10 months during the
  • No memory effect so that battery can be charged and discharged slowly.
  • With a wide range of temperatures for the working environment, -20℃ ~ +55℃, circulation span and discharging performance are well under high temperature.
  • Less volume, lighter weight.



Canadian Solar 550Watt Mono Solar Panel

Canadian Solar’s Mono PERC Modules take the best of 2 technologies and combine them into one. Mono-crystalline cells are manufactured from high-quality silicon crystals which have better performance in lower light, longer lifespan, and higher efficiency rates.

Traditional solar cell technology incorporates an emitter layer on the front surface and a black coating on the rear side of the panel. The latest method, Passivated Emitter and Rear Cell (PERC) uses dielectric passivation film on the rear surface of the solar cells. The newer method, Mono PERC, can absorb sunlight on the front surface. As well as reflected light on the surface. This increased absorption allows for more of the sun’s energy to be harnessed.

Module power

  • Module power up to 550W
  • Module efficiency up to 21.5 %
  • Up to 4.5 % lower LCOE
  • Up to 5.6 % lower system cost
  • Comprehensive LID / LeTID mitigation technology, up to 50% lower degradation
  • Compatible with mainstream trackers, cost-effective product for utility power plant
  • Better shading tolerance

More reliable

  • Minimizes micro-crack impacts
  • Heavy snow load up to 5400 Pa, wind load up to 2400 Pa*
  • Connection: EVO2
Canadian Solar 550W panels are utilized in the following areas:
  • Residential
  • Small Commercial (0 – 50kW)
  • Large Commercial



This package Includes:

  • 12 x 550w Canadian solar panels
  • 1 x 8kva Sunsynk Inverter
  • 2 x 5.1kw Dyness Lithium batteries
  • 8 x 3.5m Rail
  • 30m x 6mm Red solar cable
  • 30m x 6mm Black Solar cable
  • 24 x solar panel roof hooks
  • 20 x PV Mid Lock
  • 8 x PV End Lock
  • 1 x Combiner box 1in 1out
  • 1 x latch fuse holder
  • 2 x 125A fuse
  • 2 x 25mm Battery Cable
  • 4 x Rail extenders

NB: (Courier for panels are at your own risk, should a solar panel get damaged during shipping, Invert Solar will not be held liable for the replacement of the solar panel)

Warranties:
All inverters and batteries must be installed by a qualified electrical wireman or Master electrician with a valid registration with the Department of Labour. A valid electrical certificate of compliance (COC) must be issued once installed, specific to the installation of the backup or solar system. The installation must be compliant with SANS 10142 and ALL its parts. Any warranty claim submitted without installation photos, a valid COC, and proof of a qualified wireman/master electrician installing the unit, can be rejected and will render the warranty claim null at void.
