2.56kWh 24V Felicity Lithium Battery
The 2.56kWh 24V Felicity Lithium Battery is a compact LiFePO₄ energy storage unit built for home, office, and small commercial applications.
Engineered with a smart BMS, strong output capability, and wall- or floor-mount installation options, this battery offers reliable, safe, and long-lasting performance for both off-grid and hybrid energy systems.
With support for parallel expansion up to 38.4kWh, it is ideal for users requiring scalable and efficient power storage.
Product Features
- Stable and safe LiFePO₄ chemistry with long service life.
- 2.56kWh usable capacity suitable for smaller solar or backup systems.
- Built-in Smart BMS providing over-voltage, under-voltage, over-current, and temperature protection.
- Supports up to 15 batteries in parallel (38.4kWh).
- RS485 / CAN communication for compatibility with leading inverter brands.
- LCD + LED display for SOC, voltage, power, and system status.
- Flexible installation — wall-mounted or floor-mounted.
- Over 6,000 cycles at 80% depth of discharge.
Specifications
- Model: FLA24100
- Usable Capacity: 2.56kWh
- Battery Type: LiFePO₄
- Nominal Voltage: 25.6V
- Operating Voltage: 22–28.8V
- Recommended Charge/Discharge Current: ≤100A
- Recommended Charge/Discharge Power: ≤2,500W
- Maximum Charge/Discharge Current (15s): 150A
- Maximum Charge/Discharge Power (15s): 3,750W
- Depth of Discharge (DOD): 80%
- Scalability: Up to 15 units in parallel (38.4kWh)
- Communication: RS485 / CAN
- Protection Level: IP21
- Cycle Life: ≥6,000 Cycles
- Charging Temperature: 0–55°C
- Discharging Temperature: –20–55°C
- Display: LCD + LED
- Installation: Wall-Mounted / Floor-Mounted
- Protection: Smart BMS, Breaker, Fuse
- Net Weight: 27kg
- Gross Weight: 30kg
- Product Dimensions: 454 × 380 × 154 mm
- Package Dimensions: 543 × 472 × 232 mm
- Warranty: 7 Years
What’s in the Box
- 1 × 2.56kWh Felicity Lithium Battery
- 1 × RS485/CAN Communication Cable
- 1 × Battery Parallel Cable (35mm²)
- 1 × Wall-Mount Bracket Set
- 1 × User Manual
- 1 × Warranty Card
System Overview
- Suitable for small home backup systems, off-grid setups, and hybrid solar solutions.
- Expandable up to 38.4kWh for larger energy requirements.
- Smart BMS ensures safe and efficient operation in all environments.
- Compatible with hybrid and off-grid inverters via RS485 / CAN protocols.
Warranties:
All inverters and batteries must be installed by a qualified electrical wireman or Master electrician with a valid registration with the Department of Labour. A valid electrical certificate of compliance (COC) must be issued once installed, specific to the installation of the backup or solar system. The installation must be compliant with SANS 10142 and ALL its parts. Any warranty claim submitted without installation photos, a valid COC and proof of a qualified wireman/master electrician installing the unit, can be rejected and will render the warranty claim null and void.
