1kW Felicity IVCM1012 Off-Grid Inverter
The Felicity Solar IVCM1012 is a compact and efficient pure sine wave inverter designed for small residential backup systems and off-grid applications.
With configurable charging parameters, built-in MPPT solar charge controller, Turbo Mode, and comprehensive protection, it delivers stable, reliable power for essential household loads.
Product Features
- Configurable input voltage range for home appliances and personal electronics via LCD settings.
- Adjustable battery charging current based on battery type via LCD control.
- Turbo Mode: Supports up to three times the rated load for short durations (as shown on the product parameters table, page 1) :contentReference[oaicite:1]{index=1}.
- Configurable AC/Solar charger priority via LCD.
- Compatible with mains input or generator power.
- Built-in MPPT solar charge controller for improved solar efficiency.
- Automatic restart while AC power is recovering.
- Pure sine wave inverter for safe operation with sensitive devices.
- Cold-start function enabled.
- Overload, over-temperature, and short-circuit protection built-in.
Specifications
- Model: IVCM1012
- Rated Output Power: 1000W / 1000VA
- Instant Output Power: 2000VA (Turbo Mode)
- Nominal DC Voltage: 12V
- Nominal AC Input Voltage: 230V AC
- AC Input Voltage Range: 90–280V AC (selectable modes)
- Input Waveform: Pure sine wave
- Transfer Time: 10ms (typical UPS) / 20ms (typical appliances)
- Efficiency (Line Mode): >95% (Rated R load, battery fully charged)
- Low Line Voltage Disconnect: 170VAC/75VAC (UPS/Appliances)
- Low Line Voltage Re-connect: 180VAC/75VAC (UPS/Appliances)
- PV Max Open-Circuit Voltage: 50V
- Operating PV Voltage Range: 15–25V
- Max PV Input Power: 550W
- Max Solar Charging Current: 50A
- Max AC Charging Current: 20A
- Combined Max Charging Current: 70A
- Charge Current Regulation: 10–20A (adjustable to 10A)
- Overload Protection (SMPS Load): 5s @ 150% load / 10s @ 110–150% load
- Nominal Output Voltage: 230V AC
- Waveform: Pure sine wave
- Weight: 5.5kg
- Product Dimensions (D×W×H): 328 × 220 × 70 mm
- Package Dimensions: 422 × 314 × 182 mm
- Operating Temperature: –10°C to +55°C
- Warranty: 2 Years
What’s in the Box
- 1 × Felicity IVCM1012 Off-Grid Inverter (1kW)
- 1 × User Manual
- Battery Cable Set
- AC Input Cable
- Mounting Hardware (where applicable)
Warranties:
All inverters and batteries must be installed by a qualified electrical wireman or Master electrician with a valid registration with the Department of Labour. A valid electrical certificate of compliance (COC) must be issued once installed, specific to the installation of the backup or solar system. The installation must be compliant with SANS 10142 and ALL its parts. Any warranty claim submitted without installation photos, a valid COC and proof of a qualified wireman/master electrician installing the unit, can be rejected and will render the warranty claim null and void.
